Name: Tungsten Carbide First Punch for Screw Making VA80 Material
Brand: Chongqing Henghui Precision Mold Co., Limited
SKU: Προσαρμοσμένος
Price: 250.00 USD
Availability: InStock

Σπίτι > προϊόντα > Χτυπήματα και Σκοπίδια Καρβιδίου >

Tungsten Carbide First Punch for Screw Making VA80 Material

tungsten carbide first punch

screw making carbide punch

VA80 material carbide punch

Τόπος καταγωγής:

Chongqing, Κίνα

Μάρκα:

Henghui

Αριθμό μοντέλου:

Προσαρμοσμένος

Επικοινωνήστε μαζί μας

Ζητήστε μια προσφορά

Tungsten Carbide First Punch for Screw Making VA80 Material

Λεπτομέρειες για το προϊόν

Λειτουργία διαμόρφωσης:

Σφυρηλατητές

Υλικό προϊόντος:

Χάλυβας & Καρβιδίου

Υλικά θήκης:

H13, SKD61

Υλικό καρβιδίου:

VA80

Ακρίβεια:

+/- 0.01mm

Λογισμικό σχεδιασμού:

CAD

Επιφανειακή επεξεργασία:

Στίλβωμα

Περιεκτικότητα σε κοβάλτιο:

20%

Μέγεθος κόκκων:

3~6

Πυκνότητα:

13.58 g/cm2

Σκληρότητα:

84.0 HRA

TRS:

280 kgf/mm2

Αντοχή επιπτώσεων:

0,85 kgf/m-cm²

Σχετική απόκλιση:

0,005 χιλιοστά

Ομοκεντρικότητα:

0,01 mm

Όροι πληρωμής και αποστολής

Ποσότητα παραγγελίας min

ΣΧΕΤΙΚΑ ΠΡΟΪΟΝΤΑ

High Precision Carbide Die for Screw Extrusion Mould

Πάρτε την καλύτερη τιμή

Custom Hex Trimming Die Carbide CVD Coating Industrial Mold

Πάρτε την καλύτερη τιμή

Custom Tungsten Carbide Die Mold for Nuts M12-M20 Forging Mould

Πάρτε την καλύτερη τιμή

DC53 Thread Rolling Dies for Self Tapping Screw Making Molds

Πάρτε την καλύτερη τιμή

Επικοινωνήστε μαζί μας

+8613983025528

hou@citool.com

86-023-60338218-60338218

Επικοινωνήστε τώρα

Περιγραφή του προϊόντος

Customized Processing Factory Shipment International Express Transportation Cold Heading Punch Die

Product Specifications

Shaping Mode	Forging Mould
Product Material	Steel & Carbide
Product	screw die
Product Name	Tungsten Carbide First Punch
Case Material	H13, SKD61
Carbide Material	VA80
Precision	+/- 0.01mm
Design software	CAD
Usage	For Making Screws
Surface	Polishing
Service	OEM ODM

Product Description

Main material: Reasonable choice of carbide material will greatly improve the service life of die.

Material Specifications

Item	Co	Grain Size	Density	Hardness	TRS	Impact Strength	Application
KG2	6.5%	2~3	14.90	90.5	320	0.28	Drawing die
KG3	9%	2~3	14.61	89.3	340	0.52	Extrusion die
KG5	12%	2~3	14.31	88.3	340	0.58	Extrusion die
KG6	14%	2~3	14.12	87.3	320	0.65	Extrusion die
ST6	15%	3~6	13.80	86.0	270	0.78	Stainless steel
ST7	20%	2~6	13.40	85.3	270	0.80	Stainless steel
EA65	18%	2~6	13.73	85.0	300	0.80	Carbon steel screw/cutting die
VA80	20%	3~6	13.58	84.0	280	0.85	Impact resistance
VA90	22%	6~9	13.39	82.5	240	0.90	Impact resistance

Quality Assurance

Manufacturing Facility

Company Profile

Chongqing Henghui Precision Mold Co., Ltd. is equipped with advanced manufacturing equipment including CNC lathes, machining centers, cylindrical grinding machines, EDM machines, and cutting machines. Our quality assurance is supported by Rockwell Hardness Testers, Projectors, and 3D Image Measuring Instruments.

We specialize in designing and manufacturing high-quality precision molds for cold heading and hot upsetting industries, with dimensional accuracy controlled within 0.005mm and concentricity within 0.01mm. Operating under ISO9001:2015 quality management system, we serve global clients in Southeast Asia, Europe, and the United States with our commitment to "Customer first, quality first, technology first, dedicated service".

Industry Participation

We actively participate in international fastener exhibitions including the German Fastener Exhibition and Indian Fastener Exhibition, where we showcase our products and establish valuable business connections.

Packaging & Delivery

Packaging Details: Carton Box; Export Standard Package, or as per client's requirements.

Delivery Time: 12-45 days depending on order quantity.

Frequently Asked Questions

Q1: How can I get a quotation from your company?

A1: Contact us with the following information for prompt quotation: drawings, material specifications, quantity requirements, and surface treatment preferences.

Q2: What is our lead time?

A2: Production lead time depends on order quantity and destination country.
